G3 SP PUMP,G3-G-ACSP-4L0L00-1D000000 - 96G228 - Graco
Anterior
Siguiente
Producto auténtico de GRACO, con la referencia 96G228 y la descripción PUMP,G3-G-ACSP-4L0L00-1D000000, que se encuentra actualmente en nuestro catálogo y es distribuidopor el Servicio Oficial de GRACO.
Calificación:
(0)
- Plazo de entrega: 48 horas
close
Producto auténtico de GRACO, con la referencia 96G228 y la descripción PUMP,G3-G-ACSP-4L0L00-1D000000, que se encuentra actualmente en nuestro catálogo y es distribuido por el Servicio Oficial de GRACO.
Especificaciones operativas
| Producto UPC | 755652420859 |
|---|---|
| Division | LED |
| Price Block | 125 |
| Country of Origin | US |
| Unidad de medida | EA |
| Altura | 39 CM |
| Longitud | 32 CM |
| Anchura | 29 CM |
| Volumen | .036 M3 |
| Shipping Weight | 7.62 KG |
Especificaciones técnicas
| Fluid Outlet Size (mm) | 6.3500 |
|---|---|
| Fluid Outlet Thread Gender | Hembra |
| For Use With | Sistemas de serie progresiva |
| Includes | Bajo nivel con controlador |
| Maximum NLGI Grade | #2 |
| Maximum Working Pressure (bar) | 351.6 |
| Maximum Working Pressure (kPa) | 35160 |
| Maximum Working Pressure (psi) | 5100 |
| Model | G3 |
| Reservoir Size (gal) | 1.06 |
| Series | SP |
| Alarm Relay Inductive Maximum Operating Current (A) | 1.5 |
| Alarm Relay Inductive Maximum Operating Voltage (VAC) | 250 |
| Alarm Relay Inductive Maximum Switching Capacity | 25 VA;30 W |
| Alarm Relay Inductive Minimum Permissible Load | 10 ?A;10m VDC |
| Alarm Relay Inductive Rated Load (A) | 0.2 |
| Alarm Relay Resistive Maximum Operating Current (A) | 3 |
| Alarm Relay Resistive Maximum Operating Voltage (VAC) | 250 |
| Alarm Relay Resistive Maximum Switching Capacity | 50 VA;60 W |
| Alarm Relay Resistive Minimum Permissible Load | 10 µA;10m VDC |
| Alarm Relay Resistive Rated Load (A) | 0.4 |
| Control Options | Serie progresiva |
| Input Cycle Rate (Hz) | 8 |
| Input Impedance | 1.1 |
| Input Load Current (mA @ 24 VDC) | 22 |
| Input Maximum Off Current (mA) | 1.5 |
| Input Maximum Residual Voltage (V) | 4 |
| Input Required Switch Type | Normalmente abierto |
| Input Response Time (ms) | 60 |
| Input Sensor Voltage (VDC) | 24 |
| IP Rating | IP69K |
| Low Level Carry Current (A) | 1.2 |
| Low Level Contact Rating (W) | 10 |
| Low Level Switch Rating (VDC) | 200 |
| Low Level Switching Current (A) | 0.5 |
| Maximum Fill Inlet Pressure (bar) | 344.7 |
| Maximum Fill Inlet Pressure (kPa) | 34470 |
| Maximum Fill Inlet Pressure (psi) | 5000 |
| Maximum Run Time (min) | 30 |
| Maximum Voltage (V ac) | 264 |
| Minimum Voltage (V ac) | 88 |
| Number of Machine Count Sensor Inputs | 1 |
| Number of Pressure and Cycle Sensor Inputs | 3 |
| Number of Pump Elements | Hasta 3 |
| Number of Sensor Inputs | 1 |
| Overall Depth (cm) | 25.4 |
| Overall Depth (in) | 10 |
| Overall Depth (mm) | 254 |
| Overall Height (cm) | 36.8 |
| Overall Height (in) | 14.5 |
| Overall Height (mm) | 368 |
| Overall Width (cm) | 23.5 |
| Overall Width (in) | 9.25 |
| Overall Width (mm) | 235 |
| Pump Output with 0 Spacers (cu in/min) | 0.25 |
| Pump Output with 1 Spacer (cu in/min) | 0.18 |
| Pump Output with 2 Spacers (cu in/min) | 0.12 |
| Vent Valve Maximum Operating Current (A) | 2 |
| Vent Valve Maximum Operating Power (W) | 48 |
| Vent Valve Output Voltage (VDC) | 24 |
| Weight (kg) | 6 |
| Maximum Working Pressure (MPa) | 35.1 |
